Hydrogen generator
The Netherlands’ leading provider
Our hydrogen generators
WM200
250 KVA
70 kW FC
Scalable up to 1 MW
WM250
250 KVA
150 kW FC
Scalable up to 1 MW
In development
WM900
1.000 KVA
600 kW FC
Scalable up to 3 MW
The advantages of the Watermeln generators
High uptime
- High electrical reliability
- Guaranteed certainty with All-in Hydrogen Service
- Uninterrupted 24/7 power
Scalable
- Scale up to 1MW
- Modular design
Online monitoring
- Remote monitoring 24/7
- Control from any device
- Smart ML & AI intergration
WM-200
The mobile hydrogen generator based on fuel cell and battery technology. The unit can operate in 3 operational modes: stand-alone off-grid, grid-connected, or with an additional battery for peak load.
-
Power
- Peak 350 kW AC
- Battery: 200 kW AC (rated power)
- Fuel cell: 70 kW AC (rated power)
-
Capacity
- Battery: 120 kWh
-
Output
- 2x Powerlock 360A
- 2x 125A 5p
-
Input
- Hydrogen 5.0 quality
- Input: 30-35 bar (quick connect), minimum input 20 bar
- Grid-connected: 22 kW 63A 5P
-
Operational temperature
- -15 tot 45 °C
- (active conditioning)
-
Weight and dimensions
- 4500 kg
- 2,99 x 2,44 x 2,59 meter (LxWxH; 10ft container)
-
Gas Control (External)
- HP connector: Staubli RBL06 of ISO 5145 No. 38 W30 2x LH
- Input: max 450 bar working pressure
- Output: 30-35 bar (Quick connect)
-
Certification
- ADR transport (class-9)
- CE certification (NEN-EN-ISO 12100:2010)
- NEN-EN 13854:2019, NEN-EN-IEC 60204
- PED 2014/68/EU SEP art. 4.3
- Explosion safety documentation (ESD ATEX)
-
Monitoring & control
- GPS & 4G online monitoring and commando's 7 inch control and monitoring touchscreen
WM250
The mobile hydrogen generator based on fuel cell and battery technology. The unit can operate in three distinct modes: standalone off-grid, grid-connected, or coupled with an additional battery for peak load management.
-
Power
- Peak: 350 kW AC
- Battery: 200 kW AC (rated power)
- Fuel Cell: 150 kW AC (rated power)
-
Capacity
- Battery: 240 kWh
-
Output
- 2x Powerlock 360A
- 2x CEE 125A
-
Input
- Fuel: Hydrogen 5.0 grade
- Maximum Input Pressure: 450 bar (Staubli RBL06)
- Operating Pressure: 30–35 bar (Swagelok quick connect), minimum input 20 bar
- Power: 1x 63A 5P (max 22 kW)
-
Operational temperature
- -15 tot 45 °C
-
Weight & demensions
- 5.500 kg
- 2,99 x 2,44 x 2,59 meter (LxBxH; 10ft container)
Book your Watermeln generator now
After filling out the form, the Watermeln team will get in touch as soon as possible.
